Rubber Wedge & 'E' Gasket for Windows and Doors

Name: Rubber Wedge & E Gasket
Brand: Extrudaseal
SKU: EXT-2122-1001
Price: 14.59 GBP
Availability: InStock

(Choice of type and length)

Seals draughty window and door units!

These gaskets are frequently paired, with 'E' Gaskets used on one side of the frame, and the Wedge Gasket on the reverse. They create a watertight and draught-proof seal between a window or door frame, and it's double-glazed unit or infill panel.

Replacing gaskets is quick and easy and requires minimal tools, and doing so can stop water ingress, eliminate draughts and noise, improve energy efficiency, safety and security.

Features & Benefits

Seals between double-glazed unit and frame
Stops water ingress, draughts and noise
Durable core strengthens and resists overstretch
Long-lasting UV stable and weather resistant
Replacing inefficient seals reduces energy bills
Fit easily without special tools or adhesive

Explanation of Wedge and 'E' Gaskets

As their name suggests, Wedge gaskets are wedge shaped, so they can simply push into place between frame and double-glazed unit. They feature a rib that hooks onto the frame to keep it in place. Wedge gaskets are designed for easy fitting, and also easy removal, should a unit need to be changed, or 'E' gaskets replaced on the other side.

'E' Gaskets get their name from their profile, which can resemble the letter E, and are also referred to as Fir Tree gaskets because they resemble the downward slopping branches of a fir tree. A mushroom extrusion that runs along these gaskets is pushed tightly into a groove in the profile. Then under compression against the double-glazed unit, the branches of the fir tree create multiple seals.

How to get the right gasket

Knowing the name of your window or door profile may help identify the gasket needed, as may be comparing the following drawings to the profile of your existing gasket. Perhaps the most trusted method is to purchase a sample pack, and testing the samples in your actual gasket groove.

Window and Door Wedge and E Fir Tree Gasket Replacement Seals

DID YOU KNOW?These are made from a Thermoplastic Elastomers (TPE) material, a blend of plastic and elastic polymer. So they're durable, thermally efficient, with a core of polypropelene (PP), or PVC nitrile, to resist overstretch and expansion.

Overview Video

Contents

Fitting & Usage

Fitting Window and Door Wedge Gasket

Wedge gasket seals are normally fitted in four pieces, with mitred ends for a neater seal. There will be a piece for each side of the unit, as well as one for both the top and bottom.

When replacing Wedge gaskets, it's important that you only replace one piece at a time, so that the beading on the other side and the glazing remain secure. Start by levering out the end of a seal, taking care that you don't damage the frame. Once the end if free, you should be able to remove the rest of the seal by hand.

Cut replacement wedge gasket 5% longer than measured, to allow for any shrinkage of the gasket over time. To fit, just position one end tight into the corner and push down between frame and glass/panel along its length to the opposite corner.

Fitting Window and Door 'E' Gasket

'E' Gaskets are clipped into the frame or bead, which makes them the most challenging to replace. Removal of the old gasket and fitting of the new, usually requires removal of the beading and sometimes also the glazing.

If the frame uses a combination of Wedge and 'E' gasket, then removing the Wedge gasket first will allow the beading to be more easily removed. When removing beading, take great care to avoid snapping or cracking, as sourcing replacement beading can be very difficult. Long beads will flex more than short beads, so remove those first. A fairly stiff wallpaper scraper of 4-5 inches can be used; just position half way along the bead, between bead and frame, and lever off. The first bead can be difficult, but the remaining beads will be easier.

When putting beads back, start with the shorter beads, and finish with the longer ones. A rubber hammer can be used to knock the beads back into place.

Please note that many modern frames have coextruded gaskets, which are welded to the frame or bead. Some are welded to an old profile, which still has the gasket groove. In such a case, a replacement gasket can be fitted to the unused groove.

A Gasket Roller can greatly speed installation of wedge gasket, and Mitre Shears help to create clean mitred cuts.

Looking after your Wedge and 'E' Gaskets

To aid during installation, many seals are coated in a non-hazardous lubricant, which can be removed with warm soapy water. Subsequent cleaning should be done with soapy water. Avoid the use of household solvents as they can degrade the seals.
