Hinged Screw Caps

Hinged Screw Caps

SKU: TIM-2417-1001
MPN: SHCCWHITEP

£3.50

Sale

Tax included. Shipping calculated at checkout.

21 in stock

Quantity

View full details

Description

Hinged Screw Cap Fixing Covers

Name: Hinged Screw Caps
Brand: TIMCO
SKU: TIM-2417-1001
Price: 3.5 GBP
Availability: InStock

(Choice of colour and size)

Hides screws, covers edges, fights corrosion—and never goes missing

Professional hinged screw caps designed to conceal exposed screw heads and deliver a seamless, finished appearance across any project. The integrated hinge prevents caps from detaching during its lifetime and provides easy access whenever adjustments are needed.

Clicks securely into place to keep out moisture and debris, reducing corrosion and extending the life of the fixing. Sharp edges are eliminated for added safety in homes, workplaces, and public environments. Available in Small and Large in a choice of colours for seamless blending with a variety of surfaces, materials, and environments.

Features & Benefits

Professional Concealment – Neatly hides exposed screw heads for a clean, uniform finish
Hinged Design – Integrated hinge prevents cap loss and provides quick access when required
Protective Barrier – Snaps firmly closed to shield the screw head and help slow corrosion
Safety First – Smooth, snag-free finish covers sharp screw edges
Colour-Matched Options – Discreet blending with timber, metal, uPVC, melamine boards, walls, and vehicle interiors

Uses

White – walls, melamine boards, kitchens, bathrooms, uPVC
Light Grey – aluminium, steel, modern interiors, office furniture
Dark Grey – darker metals, anthracite grey finishes
Brown – timber, MDF, chipboard, furniture, doors, windows
Black – industrial, commercial interiors, electronics, modern furniture
Blue – EU number plate mounts, marine, caravan, signage
Yellow – UK registration plates, safety signage, industrial marking

Specification

Specification	Small Caps	Large Caps
Pack Size	100 pieces	50 pieces
Screw thread compatability	3.0–4.5mm (Gauge 4–9)	5.0–6.0mm (Gauge 10–12)
Max. screw head diameter	10mm	15mm
Cap diameter (external)	13mm	17.5mm
Cap height (external)	5.5mm	6.5mm
Weight (per cap)	0.4g	0.5g
Colours	White, Grey, Dark Grey, Brown, Black, Blue, Yellow	White, Grey, Dark Grey, Brown, Black
Material	Plastic

Contents

Fitting & Usage

Hinged screw caps are suitable for interior and exterior use where a professional, finished appearance is required. Choose colour and size according to screw type and surface material:

Preparation

Select the correct cap size for your screw. Small caps fit screws 3.0–4.5mm (gauge 4–9). Large caps fit screws 5.0–6.0mm (gauge 10–12). Ensure the screw head is clean and free from debris before fitting.

Application

Place the screw through the cap opening
Drive the screw into the surface as normal – it may be easier to hold the cap nearer the head
Once the screw is fully tightened, press the hinged lid firmly closed until it clicks into place
Do not overtighten the screw, as this may distort the cap or damage the installation surface

Removal

To access the screw, simply lift the hinged lid using a fingernail or small flat-head screwdriver. The cap remains attached to the base, preventing loss and allowing reuse. Remove or adjust the screw as required, then press the lid back into place once finished.

Health & Safety

Small parts present a choking hazard. Keep out of reach of children.
Caps are for cosmetic and protective purposes only; they are not load-bearing and should not be used as structural fixings.

Additional Remarks

Suitable for most standard screw heads; verify fit before full installation.
For exterior use, caps help slow corrosion but do not guarantee complete waterproofing.
